Covidien Nellcor PM100N

Description

Covidien PM10N Description:

• Hand-held pulse oximeter for spot-checking and continuous monitoring.
• 3-inch color LCD display for easy reading and accurate SpO2 and pulse rate measurements.
• Adjustable alarm system for high and low SpO2, high and low pulse rate, and Set seconds.
• Suitable for use on patients ranging from neonates to adults.
• Supports robust data set including real-time SpO2 and PR values, SatSeconds alarm management, pleth waveform, blip bar, and tabular trend data.
• Compatible with a wide range of Nellcor sensors with OxiMax technology.
• Offers 80 hours of data storage capability and supports data export to an external personal computer for analysis.

Covidien PM10N Specifications:

• Dimensions:
  • Size: 2.76 W x 6.14 H x 1.26 D inches (70 x 156 x 32 mm)
  • Weight (w/ Batteries): 0.604 lbs (274 g)
• Performance:
  • SpO2 Saturation Range: 1% – 100%
  • Heart (Pulse) Rate Range: 20 – 250 bpm
  • Perfusion Range: 0.03% to 20%
  • Display Sweep Speed: 6.25 mm/sec
  • Memory: Saves a total of 80 hours of data events
• Measurement Accuracy:
  • Saturation: ± 2 digits for adult (70% to 100%), ± 3 digits for adult and neonate low saturation (60% to 80%), ± 2 digits for neonate (70% to 100%), ± 2 digits for low perfusion (70% to 100%), ± 4 digits for adult and neonate with motion (70% to 100%)
  • Pulse Rate: ± 3 digits for adult and neonate (20 to 250 bpm), ± 3 digits for low perfusion (20 to 250 bpm), ± 5 digits for adult and neonate with motion (20 to 250 bpm)
• Physical Characteristics:
  • Display Screen Size: 3.5 in (88.9 mm) measured diagonally
  • Display Screen Type: TFT LCD, white LED backlight
  • Display Resolution: 320 x 480 pixels
• Power Characteristics:
  • Battery: 4 x Type Lithium AA 1.5V or rechargeable batteries
  • Operation Time: Typically 20 hours with no external communication, no audible alarm sound, and an ambient temperature of 25°C
