Datascope Passport 2
Description
Features:
- Intended for intra-hospital use, the Datascope Passport 2 is a vital signs monitor offering comprehensive monitoring capabilities.
- Features an intelligent display interface for quick patient status evaluation, with concise and logically presented data.
- Aligns waveforms with digital data for immediate interpretation, offering easily configurable graph and list displays according to user preference.
- Equipped with 4 Auto-Set Alarms for quick configuration and ease of use, with personalized custom settings retained on PCMCIA cards for super-fast setup.
- Monitors various parameters including ECG, Masimo SET SpO2, Nellcor Axismart or OxiMax SpO2, Non-invasive Blood Pressure, Respiration Rate, and Temperature.
- Optional parameters include 3 lead or 12 lead ST analysis with adjustable ISO and J points, Arrhythmia analysis, Invasive Blood Pressure, Gases, Microstream CO2, and 12 lead ECG interpretation.
- Mounting options include rolling stand, wall mount bracket, gas machine arm, bed-rail, or tabletop operation, with compatibility for Gas Module attachment.
Passport 2 Specifications:
- Display:4” color TFT display
- Waveforms: 3 to 6 waveforms with automatic expansion
- Numerics: Auto-adjustable large numerics
- Monitoring Parameters: ECG (3 or 5 lead), NIBP, Masimo SET motion-tolerant SpO2, Temperature
- Additional Features: 6-minute OXY-CRG trend for neonatal and pediatric applications, built-in power supply for direct AC connection
- Dimensions:
- Height: 9.5″ (24.1 cm)
- Width: 11.9″ (39.2 cm)
- Depth: 7.4″ (18.8 cm)
- Weight:
- With 2 batteries: 14.3 lbs. (6.5 kg)
- Without batteries: 11.4 lbs. (5.2 kg)
- Battery Requirements:
- 2 sealed lead acid batteries, 12 Vdc @ 2.3A load, 2.3 AH each battery
- Run Time:
- 2 hours +/- 6 minutes from two fully charged batteries at 25°C with specified monitoring parameters
- Recharge Time: 16 hours maximum
- Power:
- AC Voltage: 100-240 VAC +/-10% 50/60 Hz Single Phase
- Power Consumption: 60-72 watts, 0.6-0.3 Amps
