GE MAC 5500 HD
Description
Features:
- Portable electrocardiography system with advanced and accurate readings.
- Offers 3, 6, 12, or 15-lead resting EKG and stress test readings.
- Equipped with a 10.4-inch color display for easy waveform visualization.
- Provides tools such as ACS detection, Analysis, ACI-TIP, and P wave signals.
- Capable of displaying and recording ECG information for both adult and pediatric patients.
- Can be connected to the GE Muse system for data storage and transfer via Ethernet or wireless connection.
- Better triaging tools for Acute Coronary Syndrome (ACS) detection.
- Configurable critical values to expedite treatment.
- More accurate pacemaker detection for advanced interpretation of paced rhythms.
- Enhanced barcode workflow with orders and ADT download capability to improve efficiency.
- Connected ECG Workflow to save time and avoid misdiagnoses.
- Advanced algorithms in ECG analysis and interpretation.
Specifications:
- Dimensions (Console):
- Height: 3.7 in (9.4 cm) (With display closed)
- Width: 15 in (38.1 cm)
- Depth: 13.8 in (35.1 cm)
- Weight: 15 lb (6.8 kg)
- Display:
- Type: 10.4 in diagonal graphics backlit color AM LCD
- Resolution: 640 x 480 pixels with waveform enhancement
- Power:
- Power Supply: AC or battery operation
- Voltage: 100 to 240 VAC
- Battery Type: User replaceable, rechargeable NiMH
- Battery Capacity: 100 single-page reports or six hours of continuous display (without printing)
- Environmental Operating Conditions:
- Temperature Range: 50°F to 104°F (10°C to 40°C)
- Relative Humidity: 20% to 95% RH non-condensing
- Atmospheric Pressure: 5700 to 1060 hPa
