Masimo Radical 7

Single Product Request Form
Category

Description

Masimo Radical 7 Features:

  • Non-invasive pulse oximeter monitor.
  • Monitors arterial oxygen saturation (SpO2), pulse rate, and perfusion index.
  • Measures hemoglobin (SpHb), carboxyhemoglobin (SpCO), total oxygen content (SpOC), methemoglobin (SpMet), pleth variability index (PVI), and oxygen reserve index (ORI).
  • Can function as a standard stand-alone monitor or as a handheld monitor.
  • Features a touchscreen LCD display showing numeric values and waveforms.
  • Utilizes Masimo SET technology for pulse oximetry, meeting sensitivity and specificity requirements.
  • Rainbow technology uses 7+ wavelengths to measure SpCO, SpMet, and SpHb.
  • Respiration rate can be determined by RRa or plethysmographic waveform (RRp).
  • FastStat feature tracks rapid changes in arterial O2.
  • Multi-gesture touchscreen interface and automatic screen rotation.

Masimo Radical 7 Specifications:

  • Dimensions: Handheld: Height: 8.9” (22.6 cm), Width: 3.5” (8.9 cm), Depth: 2.1” (5.3 cm), Weight: 1.2 lbs (0.54 kg). Standalone: Height: 3.5” (8.9 cm), Width: 10.5 (26.7 cm), Depth: 7.7” (19.6 cm), Weight: 3.8 lbs (1.73 kg).
  • Display: Backlit Active Matrix TFT LCD, 480 dots x 272 dots, 0.25 mm dot pitch.
  • Measurement Ranges: SpO2: 0% to 100%, SpMet: 0% to 99.9%, SpCO: 0% to 99%, SpHb: 0 g/dL to 25.0 g/dL, SpOC: 0 ml of O2/dL to 35 ml of O2/dL of blood, Pulse Rate: 25 bpm to 240 bpm, PI: 0.02% to 20%, PVI: 0% to 100%, RRa: 0 breaths per minute to 70 breaths per minute.
  • Resolution: Varies for different parameters.
  • Battery: Lithium ion, 4 hours capacity, 3 hours recharge time.
