Philips Avalon CTS M1351a

Single Product Request Form
Category

Description

Philips Avalon CTS M1351a Features:

  • Cordless transducer system for fetal and maternal monitoring, providing flexibility and mobility during labor and delivery.
  • Includes cordless toco transducer for measuring uterine activity externally.
  • Cordless ultrasound transducer measures fetal movement and heart rate.
  • Bed identifier matches transducers and base stations for each bed, ensuring accurate monitoring.
  • Base station receives transducer signals and recharges plugged-in transducers.
  • Transducer plug and play with automatic screen layout simplifies operation and allows focus on patient care.
  • Transducer status indicators provide real-time feedback on system performance.
  • Slot position indicator ensures each transducer is returned to its proper home position.
  • Cordless ECG transducer measures direct fetal ECG or maternal ECG.
  • Battery charge indicator shows the status of charge, with batteries operating for at least 16 hours.

Philips Avalon CTS M1351a Specifications:

  • Base Dimensions:
    • Width: 350 mm (13.8 in)
    • Depth: 240 mm (9.5 in)
    • Height: 75 mm (3 in)
    • Weight: 2.5 kg/5.5 lbs without transducers
  • Transducer Dimensions:
    • Size (diameter): < 10 cm/3.94 in
    • Weight: < 140 g/4.8 oz
  • Power:
    • Supply Voltages: 100 VAC to 240 VAC ± 10%
    • Supply Frequency Range: 50 Hz to 60 Hz
    • Consumption: 15 VA
  • Base Station:
    • Type of Protection Against Electrical Shock: Class I equipment
    • Input Sensitivity: -110 dBm @ 30dB Signal-to-Noise Ratio
    • Image Rejection: > 80 dB
    • Receiving Range (line of sight): approximately 100 m/300 ft
    • Antenna Input Impedance: 50 Ω
    • Water Ingress Protection Code: IP X1 (protection against vertically falling water drops)
  • Monitor Interface:
    • Toco Output Accuracy: ± 0.5% per 100 mmHg
    • Toco Output Range: 0 to 4V
    • US Voltage Range: 4mVpp to 4Vpp
    • ECG Voltage Range: 0.1Vpp to 4Vpp
  • Battery:
    • Type: Lithium Ion
    • Capacity: > 16 hours (> 700mAh)
    • Life: > 500 charge/discharge cycles
    • Transducer Storage Time: ≤ 1 year at 25°C/77°F (battery full), ≤ 1 month at 25°C/77°F (battery empty)
    • Recharging Time: 100% charged < 3h, 66% charged = 1h
  • RF Unit:
    • Nominal RF Output Power: -12 dBm ± 6 dB ERP
    • Carrier Frequency Range: See Frequency Bands
    • Minimum Frequency Band Span Per Option: 10 MHz
    • Channel spacing: 25 kHz or 12.5 kHz
  • General Transducer Specifications:
    • Shock Resistance: Withstands a 1m drop to concrete surface
    • Usability Underwater: 0.5m/1.64 ft
    • Water Ingress Protection Code: IP 68 (0.5m/1.64 ft immersion for 5 hours)
  • Environmental:
    • Temperature Range:
      • Charging: 0°C to 45°C (32°F to 113°F)
      • Operating: 0°C to 45°C (32°F to 113°F)
      • Storage (without battery): -20°C to +60°C (-4°F to 158°F)
    • Humidity Range:
      • Operating: 5% to 95% relative humidity @ 40°C/104°F
      • Storage: 5% to 85% relative humidity @ 50°C/122°F
    • Altitude Range:
      • Operating: ≤ 3000m/9800 ft
      • Storage: ≤ 15000m/49000 ft
