Schiller Cardiovit AT-1 G2 EKG Machine

Description

• Features:
  • Incorporates latest technological advancements with exceptional signal quality.
  • Easy patient data entry and outstanding signal quality for adult and pediatric ECGs.
  • High-resolution thermal printer with lead reversal detection and pacemaker recognition.
  • Integrated 3-lead thermal printer with a hook-up adviser featuring color-coded waveforms.
  • User-friendly interface with step-by-step workflow and easy-to-clean keyboard.
• Specifications:
  • Dimensions:
    • Height: 11.2 inches (28.5 cm)
    • Width: 7.4 inches (18.9 cm)
    • Depth: 2.4 inches (6.1 cm)
  • Display:
    • Size: 4.2 inches (10.8 cm) x 2.6 inches (6.5 cm)
    • Resolution: 800 x 480 dots, 5 inches.
  • Battery:
    • Capacity: Pb gel battery 12 V, 2.0 Ah, lasting 4 hours when the device is switched off.
  • Printer:
    • Chart paper: Thermo-reactive, z-folded, 80 mm wide/roll, 80 mm wide.
    • Speed: 5/25/50 mm/s, Sensitivity: 5/10/20 mm/mV.
  • ECG Display:
    • Speed: 5/25/50 mm/s, Sensitivity: 5/10/20 mm/mV.
  • Operating Conditions:
    • Temperature: 10 to 40°C, humidity: 20% to 90% (non-condensing), pressure: 780 to 1060 hPa.
