Stryker Physio-Control LUCAS 2

Single Product Request Form
Category

Description

Stryker Physio-Control LUCAS 2 Features:

  • Chest Compression System: Designed for use in patients experiencing sudden cardiac arrest, providing high-quality, consistent chest compressions to improve circulation and increase the chances of a successful outcome.
  • High-Quality Compression: Performs chest compressions at a rate of 100 compressions per minute.
  • Portable and Lightweight: Comes in a backpack for easy application to the patient, making it convenient for emergency responders.
  • No Electricity Required: Operates without the need for electrical supply, powered by breathing oxygen or air from a wall outlet.
  • Consistent Performance: Maintains consistent chest compression over a long period without fatigue.

Stryker Physio-Control LUCAS 2 Specifications:

Dimensions:

  • Height: 22” (57 cm)
  • Width: 20.5” (52 cm)
  • Depth: 9.4” (24 cm)
  • Weight: 17.2 lbs (7.8 kg)

Patient Types:

  • Suitable for adult patients with a sternum height of 6.7 to 11.9 inches (170 to 303 mm) and a maximum chest width of 17.7 inches (449 mm).
  • Not restricted by patient weight.

Compressions:

  • Compression Depth: 1.5 to 2.0 inches (4 to 5 cm) from the Start Position
  • Compression Frequency: 100 ± 5 compressions per minute
  • Compression Duty Cycle: 50 ± 5%
  • Compression Modes: Operator-selectable modes include 30:2 (30 compressions followed by a 3 seconds ventilation pause) and Continuous compressions.

Battery:

  • Type: Rechargeable Lithium-Ion Polymer (LiPo)
  • Capacity: 3300 mAh (typical), 86 Wh
  • Battery Voltage (nominal): 25.9 V
  • Initial Battery Runtime: Approximately 45 minutes (typical)
  • Maximum Battery Charge Time: Less than 4 hours at room temperature
  • Replacement Interval: Recommendation to replace the battery every 3 years or after 200 uses of more than 10 minutes each time.

Environmental:

  • Operating Temperature: +32°F to +104°F / +0°C to +40°C
  • Storage Temperature: -4°F to +158°F / -20°C to +70°C
  • Relative Humidity: 5% to 98%, non-condensing
  • IP Classification: IP 43
  • Operating Input Voltage: 12-24 V DC
