Welch Allyn ELI 280

Description

Features:

• Compact and Lightweight Design:
  • Portable electrocardiography system.
  • 1-inch color touchscreen display for easy operation.
• High-Quality ECG Capture:
  • Captures 12-lead ECG waveform data with high resolution.
  • Automatically selects and displays the best 10 seconds of ECG data.
• Efficient Data Management:
  • Stores up to 200 ECGs internally.
  • Offers standard PDF capabilities through LAN or optional WiFi connection.
  • Bidirectional communication between EHR/HIS Systems.

Welch Allyn ELI 280 Specifications:

• Dimensions:
  • Length: 17.5 in, Width: 15.5 in, Height: 4.5 in
  • Weight: 12.5 lbs including battery
• Printing:
  • Paper: Perforated Z-fold thermal paper, Smart paper, A4 or 8.5 x 11” wide, 250 sheets.
  • Thermal Printer Speeds: 5, 10, 25, or 50 mm/s.
  • Gain Settings: 5, 10, or 20 mm/mV.
• ECG Storage:
  • Internal storage for up to 40 ECGs, expandable up to 200 ECGs.
• Power Requirements:
  • Universal AC power supply (100-240 VAC at 50/60 Hz).
• Environmental Conditions:
  • Operating Temperature: +10° C to +40° C
  • Relative Humidity: 15 – 95% non-condensing
  • Altitude: 700 – 1060 hPa
